DJI FlyCart 30 Winch System Kit – DronePoint Canada

DJI FlyCart 30 Winch System enables aerial cargo loading and unloading in harsh environments where the aircraft cannot land. After installing the corresponding landing gear, the aircraft is easier to store and transport.

Whats Included:

• Winch System X 1
• Winch System Communication Cable X 1
• Landing Gear X 2
• Landing Gear Extension Rod X 4
• Landing Gear Front Rod X 1
• Landing Gear Rear Rod X 1
• Counter Weight X 1
• Cable X 1
• Extension Cable X 4
• Cable Tubes X 2
• Landing Gear Scrap X 2
• M4 Screws X 10
• M5 Screws X 3

Specifications

Model   A2EWH-30A

Weight   3.1 kg

Max Payload.  30 kg

Cable Length.  20 m

Extension Cable Length 5 m

Counter Weight.  1.9 kg

Power Supply Voltage.  52.22 V (Standard Voltage), 59.92 V (Max Voltage), 42 V (Min Voltage)

Weight Accuracy.  ±3 kg
